Запчасти Komatsu PC228USLC-8 КАБИНА, ОТВАЛ УПРАВЛ-Е ТРУБЫ (№-) КАБИНА, ДЛЯ -ДОПОЛН. АКТУАТОР ТРУБЫ, АККУМУЛЯТОР, DOZER, АВСТРАЛИЯ

1

01010-D1025

Bolt

2

01643-71032

Washer

3

22P-43-13310

Bracket

4

01010-81040

Bolt

5

01643-31032

Washer

6

22P-43-13330

Lever

7

01010-D0825

Bolt

8

01643-70823

Washer

9

01583-11408

Nut

10

22U-43-21730

Seat

11

20T-43-71110

Knob

12

20T-43-71190

Nut

13

21W-62-43980

Elbow

14

07000-12011

O-ring

15

02896-11008

O-ring

16

21W-62-43980

Elbow

17

07000-12011

O-ring

18

02896-11008

O-ring

19

11Y-62-12140

Nipple

20

07000-12011

O-ring

21

02896-11008

O-ring

22

02760-00211

Hose

23

02761-00211

Hose, Face Seal Type, Blue-White

24

20Y-62-22790

Band, Red

25

20Y-62-22810

Band, Yellow

26

20Y-62-22820

Band, Blue

27

20Y-62-22830

Band, White

28

20Y-62-22840

Band, Black

29

20Y-62-22850

Band, Green

30

22B-62-25510

Hose

31

22B-62-25520

Hose

32

22B-43-23580

Sheet

33

22B-54-16461

Rivet

34

20Y-62-43440

Bracket

35

01010-81020

Bolt

36

01643-31032

Washer

37

20Y-62-43430

Block

38

01010-80820

Bolt

39

01643-30823

Washer

40

02781-0021D

Union

41

02896-11008

O-ring

42

07002-11423

O-ring

43

02740-00225

Hose

44

02741-00227

Hose

45

20Y-62-22820

Band, Blue

46

20Y-62-22840

Band, Black

47

20Y-62-22860

Band, Brown

48

02782-10210

Elbow

49

02896-11008

O-ring

50

07002-11423

O-ring

51

206-06-61130

Switch, Pressure
