Запчасти Komatsu PC228USLC-8 РУКОЯТЬ, ЦИЛИНДР КОВША (ДЛЯ .9M РУКОЯТЬ), ДЛЯ СТРАН ЕС РУКОЯТЬ (.9M), ДЛЯ СТРАН ЕС

|$0

707-01-0CH30

Cylinder Group

1

707-13-11880

Cylinder

2

707-58-80870

Rod, Piston

3

707-76-70651

Bushing

4

07145-00070

Seal, Dust, (Kit : K06)

5

07020-00000

Fitting, Grease

6

707-76-70120

Bushing

7

20Y-70-23220

Seal, Dust, (Kit : K06)

8

07020-00000

Fitting, Grease

9

707-27-11870

Cylinder Head

10

707-56-80740

Seal, Dust, (Kit : K06)

11

07179-13094

Ring, Snap

12

707-51-80030

Packing, Rod, (Kit : K06)

13

707-51-80650

Ring, (Kit : K06)

14

707-52-90561

Bushing

15

707-35-91150

Ring, Back-up, (Kit : K06)

16

07000-15105

O-Ring, (Kit : K06)

17

01010-81670

Bolt

18

01643-51645

Washer

19

707-75-80040

Ring, Snap

20

707-36-11880

Piston

21

707-44-11250

Ring, Piston, (Kit : K06)

22

707-39-11530

Ring, Wear, (Kit : K06)

23

707-44-11920

Ring

24

01310-01216

Screw

25

07000-15070

O-Ring, (Kit : K06)

26

707-35-90360

Ring, Back-up, (Kit : K06)

27

707-86-67750

Tube

28

707-88-22570

Bracket

29

07372-21060

Bolt

30

01643-51032

Washer

31

07372-21045

Bolt

32

01643-51032

Washer

33

07000-13030

O-Ring, (Kit : K06)

34

707-88-21271

Band

35

07372-21035

Bolt

36

01643-51032

Washer

37

07283-32738

Clip, Pipe

38

01597-01009

Nut

39

01643-31032

Washer
