Запчасти Komatsu PC228USLC-8 РУКОЯТЬ, ЦИЛИНДР КОВША (ДЛЯ .M РУКОЯТЬ), ДЛЯ СТРАН ЕС РУКОЯТЬ ( .M), ДЛЯ СТРАН ЕС

G-1

707-01-XR140

Cylinder Group

|1

707-01-0J080

Cylinder Assґy

1

707-13-12590

Cylinder

2

707-76-70651

Bushing

3

07145-00070

Seal,Dust (Kit)

4

707-58-85440

Rod,Piston

5

707-76-70120

Bushing

6

20Y-70-23220

Seal,Dust (Kit)

7

707-27-12750

Head,Cylinder

8

07179-13099

Ring,Snap

9

707-56-85510

Seal,Dust (Kit)

10

707-52-90610

Bushing

11

707-75-85110

Ring

12

707-51-85030

Packing,Rod (Kit)

13

07000-15115

O-Ring (Kit)

14

707-35-91250

Ring,Back-Up (Kit)

15

707-51-85650

Ring,Buffer (Kit)

16

01010-81670

Bolt

17

01643-51645

Washer

18

721-36-12030

Piston

19

707-44-12250

Ring,Piston (Kit)

20

707-39-12560

Ring,Wear (Kit)

21

707-44-12921

Ring

22

707-35-90930

Ring,Back-Up (Kit)

23

07000-15075

O-Ring (Kit)

24

01310-01216

Screw

25

07020-00000

Fitting,Grease

26

07020-00000

Fitting,Grease

27

707-86-67820

Tube

28

07372-21060

Bolt

29

01643-51032

Washer

30

07372-21045

Bolt

31

01643-51032

Washer

32

07000-13030

O-Ring (Kit)

33

707-88-22780

Bracket

34

707-88-21530

Band

35

07372-21035

Bolt

36

01643-51032

Washer

37

07283-32738

Clip

38

01597-01009

Nut

39

01643-31032

Washer

40

707-88-33030

Head

41

07371-30640

Flange,Split

42

07372-21035

Bolt

43

01643-51032

Washer

|$46

707-99-47130

Service Kit
