Запчасти Komatsu PC228USLC-8 КОНЕЧНАЯ ПЕРЕДАЧА, ВНУТР. ЧАСТИ, МОТОР ХОДА (/) КОНЕЧНАЯ ПЕРЕДАЧА

|$0

22U-27-00141

Final Drive Assembly

|$1

22U-27-00140

Final Drive Assembly

|$2

708-8F-00220

Motor Assembly

1

708-8F-32121

Shaft

2

708-8F-12151

Bearing

3

708-7L-12140

Bearing

4

708-7L-05010

Spacer Kit

4

Spacer, T=1.5mm

4

Spacer, T=1.6mm

4

Spacer, T=1.7mm

4

Spacer, T=1.8mm

4

Spacer, T=1.9mm

4

Spacer, T=2.0mm

5

706-7G-11291

Seal, Oil

6

708-8F-12230

Spacer, T=3.2mm

7

04065-07225

Ring, Snap

8

Block, Cylinder

9

Plate

10

Pin

11

708-8F-33360

Pin

12

708-7L-13140

Seat

13

708-8F-33160

Spring

14

04065-04818

Ring, Snap

15

708-8F-33350

Guide, Retainer

16

708-2L-33350

Retainer, Shoe

17

708-8F-33310

Piston Subassembly

18

708-8F-33471

Cam, Rocker

19

708-8F-33710

Ball, Retainer

20

708-8F-34141

Piston

21

708-8F-34150

Spring

22

708-8F-35110

Plate

23

708-8F-35130

Plate

24

708-8F-35120

Disc

25

708-8F-35140

Piston, Brake

26

708-8F-35160

O-Ring

27

708-8F-35170

Ring, Back-up

28

708-8F-35180

O-Ring

29

708-8F-35190

Ring, Back-up

30

708-8F-35150

Spring

31

04025-00324

Pin, Spring
