Запчасти Komatsu PC228USLC-3S ПЕРЕДН. КРЫШКА(COVER) (/) (YELНИЗ.) ( АКТУАТОР)(№-7) ЧАСТИ КОРПУСА

1

22U-54-24131NK

COVER

2

20N-54-11160

HINGE (WELDED)

3

205-60-71220

LOCK ASS'Y

4

22B-54-12291

BRACKET

5

01010-80620

BOLT

6

01643-30623

WASHER

7

20R-54-11460

SPRING

8

01023-10406

SCREW

9

22U-54-24221

SHEET

10

22U-54-24261

SHEET

11

22U-54-24331

SEAL

12

22U-54-24661YN

HANDRAIL

13

01010-81230

BOLT

14

01643-31232

WASHER

15

22U-54-24171YN

COVER

16

01010-81225

BOLT

17

01643-31232

WASHER

18

22L-46-12150

CAP

19

01010-81245

BOLT

20

01643-31232

WASHER

21

22U-54-24570YN

COVER

22

22U-54-24250YN

COVER

23

01010-81225

BOLT

24

01643-31232

WASHER

25

01010-81230

BOLT

26

01643-31232

WASHER

|$42

22U-54-24540

COVER

27

COVER

28

22U-54-24490

SHEET

29

01010-81225

BOLT

30

01643-31232

WASHER

31

01010-D1220

BOLT

32

01643-71232

WASHER

33

22U-54-24211

BRACKET

34

01010-81225

BOLT

35

01643-31232

WASHER

36

22U-54-24430YN

COVER

37

01010-81230

BOLT

38

01643-31232

WASHER

39

01010-81230

BOLT

40

01643-31232

WASHER
