Запчасти Komatsu PC228USLC-3N-YP МЕХАНИЗМ ПОВОРОТА(№-) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

706-7G-01011

MOTOR ASS'Y

2

22U-26-21280

RING

3

07042-00312

PLUG

4

20Y-26-31110

CASE

5

20Y-26-22330

BEARING

6

20Y-26-22340

BEARING

7

20Y-26-21142

SHAFT

8

20Y-26-22420

SEAL

9

20Y-26-22191

COVER

10

01010-81045

BOLT

11

01643-31032

WASHER

12

07000-15310

O-RING

13

22U-26-21580

CARRIER

14

22U-26-21540

GEAR

15

20G-26-11240

BEARING

16

20Y-27-21240

WASHER

17

20Y-26-22250

PIN

18

20Y-27-21280

PIN

19

20Y-26-21240

PLATE

20

112-32-11211

BOLT¤ SHOE

21

22U-26-21551

GEAR

22

20K-22-11190

O-RING

23

01010-81440

BOLT

24

01643-31445

WASHER

25

22U-26-21530

GEAR

26

22U-26-21570

CARRIER

27

22U-26-21520

GEAR

28

20Y-26-21281

BEARING

29

22U-26-21230

WASHER

30

22U-26-21210

PIN

31

04064-03515

RING

32

22U-26-21250

WASHER

33

22U-26-21510

GEAR

34

195-03-13241

VALVE

35

205-26-71620

TUBE

36

07281-00197

CLAMP

37

01010-81035

BOLT

38

01643-51032

WASHER

39

22U-26-21411

TUBE

40

22U-26-21421

FILLER

41

22U-26-21460

CAP

42

22U-26-21431

GAUGE

43

22U-26-21440

BRACKET

44

07283-32738

CLIP

45

01597-01009

NUT

46

01643-31032

WASHER

47

01010-81030

BOLT

48

01643-31032

WASHER

49

07238-10630

CONNECTOR

50

04434-51710

CLIP

51

22U-26-21450

BRACKET

52

01010-81025

BOLT

53

01643-31032

WASHER

54

07000-15240

O-RING

55

01010-82060

BOLT

56

01643-32060

WASHER
