Запчасти Komatsu PC228USLC-3N-YP МЕХАНИЗМ ПОВОРОТА(№-) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

706-7G-01011

MOTOR ASS'Y

2

22U-26-21280

RING

3

07042-00312

PLUG

4

22U-26-21190

CASE

5

07029-00000

VALVE

6

20Y-26-22330

BEARING

7

22U-26-21340

BEARING

8

22U-26-21560

SHAFT¤ 15 TEETH

9

07012-00115

SEAL

10

22U-26-21270

SPACER

11

07000-15310

O-RING

12

22U-26-21580

CARRIER

13

22U-26-21540

GEAR

14

20G-26-11240

BEARING

15

20Y-27-21240

WASHER

16

20Y-26-22250

PIN

17

20Y-27-21280

PIN

18

20Y-26-21240

PLATE

19

112-32-11211

BOLT¤ SHOE

20

22U-26-21551

GEAR

21

20K-22-11190

O-RING

22

01010-81440

BOLT

23

01643-31445

WASHER

24

22U-26-21530

GEAR

25

22U-26-21570

CARRIER

26

22U-26-21520

GEAR

27

20Y-26-21281

BEARING

28

22U-26-21230

WASHER

29

22U-26-21210

PIN

30

04064-03515

RING

31

22U-26-21250

WASHER

32

22U-26-21510

GEAR

33

195-03-13241

VALVE

34

205-26-71620

TUBE

35

07281-00197

CLAMP

36

01010-81035

BOLT

37

01643-51032

WASHER

38

22U-26-21671

TUBE

39

22U-26-21661

CAP

40

22U-26-21440

BRACKET

41

07283-32738

CLIP

42

01597-01009

NUT

43

01643-31032

WASHER

44

01010-81030

BOLT

45

01643-31032

WASHER

46

07238-10630

CONNECTOR

47

6138-55-7610

NIPPLE

48

07281-00167

CLAMP

49

07286-01045

HOSE

50

07000-15240

O-RING

51

01010-82060

BOLT

52

01643-32060

WASHER
