Запчасти Komatsu PC228USLC-3N-YB ОСНОВН. НАСОС (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2L-00102

PUMP ASS'Y

|1

708-2L-01102

PUMP SUB ASS'Y

1

708-2L-32110

SHAFT,FRONT

2

708-2L-32150

BEARING

3

708-2E-05040

WASHER KIT

|3

WASHER¤ 3.1MM

|3

WASHER¤ 3.0MM

|3

WASHER¤ 2.9MM

|3

WASHER¤ 2.8MM

4

708-25-12790

RING,SNAP

5

708-25-52861

SEAL,OIL

6

708-2L-22160

SPACER

7

04065-06825

RING,SNAP

|8

708-2L-06340

BLOCK ASS'Y,FRONT

8

BLOCK,CYLINDER

9

PLATE,VALVE

10

720-68-19610

PIN

11

04065-04818

RING,SNAP

12

708-2L-23131

SEAT

13

708-2L-33160

SPRING

14

708-7L-13140

SEAT

15

708-2L-23351

GUIDE,RETAINER

16

708-2L-23360

PIN

17

708-2L-33350

RETAINER,SHOE

18

708-2L-33310

PISTON SUB ASS'Y

|19

708-2L-06190

CRADLE ASS'Y

19

CRADLE

20

CAM,ROCKER

21

04020-01228

PIN

22

01252-61230

BOLT
