Запчасти Komatsu PC228USLC-3N-YB ПЕРЕГОРОДКА. (COVER) (/) (YELНИЗ.)(№9-) ЧАСТИ КОРПУСА

|1

22U-54-22925

COVER

1

COVER

2

22U-54-22742

SHEET

3

22U-54-22752

SHEET

4

22U-54-22761

SHEET

5

22U-54-23220

SHEET

6

22U-54-23230

SEAL

7

01010-81230

BOLT

8

01643-31232

WASHER

9

20Y-54-12320

CATCH

10

01010-81230

BOLT

11

01643-31232

WASHER

|12

22U-54-22932

COVER

12

COVER

13

22U-54-22731

SHEET

14

22U-54-22821

SHEET

15

01010-81230

BOLT

16

01643-31232

WASHER

17

20Y-54-12320

CATCH

18

01010-81230

BOLT

19

01643-31232

WASHER

|20

22U-54-22944

COVER ASS'Y

20

COVER

21

22U-54-22772

GROMMET

22

22U-54-22843

SHEET

23

22U-54-23240

SEAL

24

01010-81230

BOLT

25

01643-31232

WASHER

26

22U-54-23522

COVER

27

01010-81220

BOLT

28

01643-31232

WASHER

29

22U-54-22882

COVER

30

01010-81220

BOLT

31

01643-31232

WASHER

32

22U-54-23530

COVER

33

01010-81220

BOLT

34

01643-31232

WASHER
