Запчасти Komatsu PC228USLC-3E0 ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC228USLC-3E0 - ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
2
3
3
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
19
19
20
21
22
22
23
24
25
26
27
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
45
46
46
47
48
48
49
49

Артикул

Название

Примечание

Количество

G-1

707-01-XS411

CYLINDER GROUP

G-1

707-01-XS410

CYLINDER GROUP

|$5

707-01-0H601

CYLINDER ASS'Y

|$6

707-01-0H600

CYLINDER ASS'Y

1

707-13-13870

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-95270

ROD,PISTON

5

707-27-13850

HEAD,CYLINDER

6

07179-13109

RING,SNAP

7

707-56-95510

SEAL,DUST (KIT)

8

707-52-90721

BUSHING

9

707-75-95030

RING,SNAP

10

707-51-95030

PACKING,ROD (KIT)

11

07000-15125

O-RING (KIT)

12

707-35-31260

RING,BACK-UP (KIT)

12

707-35-91370

RING,BACK-UP (KIT)

13

707-51-95650

RING,BUFFER (KIT)

14

01010-81875

BOLT

15

707-41-11840

WASHER

16

707-36-13771

PISTON

17

707-44-13250

RING,PISTON (KIT)

18

707-39-13530

RING,WEAR (KIT)

19

707-44-13920

RING

20

707-71-71010

PLUNGER

21

07000-15085

O-RING (KIT)

22

707-35-30850

RING,BACK-UP (KIT)

22

707-35-90960

RING,BACK-UP (KIT)

23

01310-01216

SCREW

24

707-71-80270

PLUNGER

25

07020-00000

FITTING,GREASE

26

707-71-34980

COLLAR

27

707-35-31260

RING,BACK-UP (KIT)

27

707-35-91370

RING,BACK-UP (KIT)

28

07000-15125

O-RING (KIT)

29

04260-00635

BALL

30

707-71-91270

CAP

31

707-83-13010

VALVE

32

07750-01628

SPRING

33

707-87-14070

PLUG

34

07002-12034

O-RING (KIT)

35

707-86-67740

TUBE

36

07372-51060

BOLT

37

01643-51032

WASHER

38

07372-51045

BOLT

39

01643-51032

WASHER

40

07000-13030

O-RING (KIT)

41

707-88-22530

BRACKET

42

707-88-21261

BAND

43

707-88-28030

BRACKET

44

707-88-21261

BAND

45

07372-21035

BOLT

46

01643-51032

WASHER

47

07283-32738

CLIP

48

01597-01009

NUT

49

01643-31032

WASHER

|$60

707-99-50500

SERVICE KIT

|$61

707-98-48610

SERVICE KIT

Выбрано товаров: 58
