Запчасти Komatsu PC228USLC-3E0 ЦИЛИНДР СТРЕЛЫ(ЛЕВ.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XP860

CYLINDER GROUP,L.H. (FINAL COATING)

|$3

707-01-0K860

CYLINDER ASS'Y

1

707-13-12640

CYLINDER

2

707-76-70651

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-58-85480

ROD,PISTON

5

707-76-80431

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-12650

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90610

BUSHING

11

707-75-85110

RING,SNAP

12

707-51-85030

PACKING,ROD (KIT)

13

07000-15110

O-RING (KIT)

14

707-35-91220

RING,BACK-UP (KIT)

15

707-51-85650

RING,BUFFER (KIT)

16

01010-81670

BOLT

17

01643-51645

WASHER

18

707-36-12851

PISTON

19

707-44-12150

RING,PISTON (KIT)

20

707-39-12140

RING,WEAR (KIT)

21

707-44-12911

RING

22

07000-15075

O-RING (KIT)

23

707-35-90930

RING,BACK-UP (KIT)

24

01310-01216

SCREW

25

707-86-68230

TUBE,L.H.

26

20Y-62-24580

TUBE,L.H.

27

07372-21060

BOLT

28

01643-51032

WASHER

29

07372-21045

BOLT

30

01643-51032

WASHER

31

07000-13030

O-RING (KIT)

32

707-88-28010

BRACKET,L.H.

33

707-88-21620

BAND

34

07372-21035

BOLT

35

01643-51032

WASHER

36

07283-32738

CLIP

37

01597-01009

NUT

38

01643-31032

WASHER

KIT

707-98-46300

SERVICE KIT
