Запчасти Komatsu PC228USLC-3-YP MALTI PATTERN (КЛАПАН)(№-) ГИДРАВЛИКА

|1

203-62-62501

VAVLE ASS'Y

1

203-62-59231

COVER

2

203-62-58911

LEVER

3

203-62-59260

PLATE

4

09822-00800

PLATE¤ OPERATING

5

BODY

6

236-10-12240

SPRING

7

203-62-58940

SHAFT

8

203-62-58980

COVER

9

01643-30623

WASHER

10

01010-80625

BOLT

11

01643-30823

WASHER

12

203-62-59270

WING BOLT

13

01640-20816

WASHER

14

04050-12015

PIN

15

07003-13642

GASKET

16

07000-13028

O-RING

17

01252-60616

BOLT

18

07043-00108

PLUG

19

04260-00793

BALL

20

07000-12060

O-RING

21

01010-81030

BOLT

22

01643-31032

WASHER

23

07235-10210

ELBOW

24

07002-11423

O-RING

25

07235-10311

ELBOW

26

07002-11423

O-RING

27

07236-10210

ELBOW

28

07002-11423

O-RING

29

20Y-62-16630

NIPPLE

29A

201-60-11390

O-RING

29B

20Y-62-19560

O-RING

30

07002-11423

O-RING

31

20Y-62-22271

ELBOW

31A

201-60-11390

O-RING

31B

20Y-62-19560

O-RING

32

07002-11423

O-RING

33

20Y-62-25720

ELBOW

34

201-60-11390

O-RING

35

20Y-62-19560

O-RING

36

07002-11423

O-RING

37

22U-62-21841

PLATE

38

01010-81230

BOLT

39

01643-31232

WASHER
