Запчасти Komatsu PC228USLC-3-YB ЛЕВ. КРЫШКА(YELНИЗ.)(№-) ЧАСТИ КОРПУСА

1

22U-54-22112NK

COVER

|1

22U-54-22111NK

COVER,L.H.

1A

22U-54-24480

LOCK (WELDED)

2

22U-54-22231NK

HINGE

3

01010-81230

BOLT

4

01643-31232

WASHER

5

22B-54-12340

BAR

6

22B-54-12330

CUSHION

7

20R-54-11460

SPRING

8

01023-10512

SCREW

9

205-54-53550

DOVE TAIL

10

01010-80616

BOLT

11

01643-30623

WASHER

12

01010-81225

BOLT

13

01643-31232

WASHER

|14

22U-54-22121

FRAME ASS'Y

|14

22U-54-22120

FRAME ASS'Y

14

FRAME

15

22U-54-23152

BRACKET

|15

22U-54-23151

BRACKET

16

01010-81230

BOLT

17

01643-31232

WASHER

18

20Y-54-11611

STOPPER

19

01580-11008

NUT

20

20Y-54-28170

BRACKET

21

01010-81230

BOLT

22

01643-31232

WASHER

23

205-54-51970

DOVE TAIL

24

01010-80616

BOLT

25

01643-30623

WASHER

26

01010-81225

BOLT

27

01643-31232

WASHER
