Запчасти Komatsu PC228USLC-3-YB КАПОТ (YELНИЗ.)(№-) ЧАСТИ КОРПУСА

|1

22U-54-21180

COVER

1

COVER

2

198-54-41982

LOCK ASS'Y (WELDED)

3

22B-54-11130

HINGE (WELDED)

4

22U-54-21120

SHEET

5

22U-54-21131

SHEET

6

22U-54-21161

SEAL

7

01010-81225

BOLT

8

01643-31232

WASHER

9

22U-54-21642

FRAME

|9

22U-54-21641

FRAME

10

01010-81230

BOLT

11

01643-31232

WASHER

12

22U-54-21661

FRAME

13

22U-54-21840

BAR

|13

22B-54-11181

BAR

14

01643-31032

WASHER

15

04050-13018

PIN

16

205-54-51970

DOVE TAIL

17

01010-80612

BOLT

18

01643-30623

WASHER

19

205-54-53550

DOVE TAIL

20

01010-80616

BOLT

21

01643-30623

WASHER

22

22U-54-21150

BRACKET

23

01010-81230

BOLT

24

01643-31232

WASHER

25

20Y-54-28182

PLATE

26

01010-81230

BOLT

27

01643-31232

WASHER

28

22U-54-21170

BRACKET

29

01010-81230

BOLT

30

01643-31232

WASHER

31

01010-81230

BOLT

32

01643-31232

WASHER
