Запчасти Komatsu PC228USLC-3-YA ОХЛАЖД-Е (РАДИАТОР)(№-) СИСТЕМА ОХЛАЖДЕНИЯ

1

22U-03-21111

RADIATOR CORE ASS'Y

2

20Y-03-22110

CAP

3

20Y-03-21980

PLUG

4

07000-01007

O-RING

5

203-03-41410

HOSE

6

20Y-03-11330

CLIP

7

01435-20816

BOLT

8

01435-20825

BOLT

9

22U-03-21132

FRAME

10

22U-03-21141

FRAME

11

22U-03-21151

FRAME

12

01010-81230

BOLT

13

01643-31232

WASHER

14

22U-03-21121

OIL COOLER

15

01010-81030

BOLT

16

01643-31032

WASHER

17

22U-03-21790

VALVE ASS'Y

18

07000-73026

O-RING

19

07002-13634

O-RING

20

07230-20210

UNION

21

07002-11423

O-RING

22

07102-202A3

HOSE

23

07376-50210

PLUG

24

22U-03-21181

NET

25

22U-03-21310

NET

26

01434-10616

BOLT¤ WING

27

01643-30823

WASHER

28

20T-03-81180

NUT

29

22U-03-21391

SHROUD

30

01435-20816

BOLT

31

22U-03-21321

SHROUD

32

01010-81020

BOLT

33

203-54-56970

WASHER

34

22U-03-21770

BRACKET

35

22U-03-21780

BRACKET

36

01010-81025

BOLT

37

01010-81030

BOLT

38

01643-31032

WASHER

39

22U-03-21191

NET

40

01434-10616

BOLT¤ WING

41

01643-30623

WASHER

42

22U-03-21212

PLATE

43

22U-03-21221

PLATE

44

01010-81020

BOLT

45

01643-31032

WASHER
