Запчасти Komatsu PC228USLC-3 БЛОК КОНДИЦИОНЕРА (/) (РУЧН. КОНДИЦ. ВОЗДУХА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

22U-979-1720

AIR CONDITIONER A.

|$2

DK534138-6620

CASE ASS'Y

1

DK534136-9201

CASE

2

DK534190-0500

LINING

3

DK534461-8802

COVER

4

DK536022-3501

WIRING HARNESS

5

DK592024-3100

CLIP

6

DK592022-3700

SCREW

7

DK595327-8100

CLIP

8

DK592022-3700

SCREW

9

DK580534-0400

CLIP

10

DK592608-0400

TAPE

|$13

DK582594-3020

RELAY ASS'Y

11

DK534104-8400

BRACKET

12

DK593111-8800

RELAY

13

DK593230-1420

RELAY

14

DK580140-0600

SCREW

15

DK582670-2501

POWER TRANSISTOR

16

DK012514-1640

SCREW

17

DK534232-2200

SEAL

18

DK502700-2520

HEATER CORE ASS'Y

19

DK580534-4300

CLIP

20

DK592022-3700

SCREW

21

DK524120-1720

PLATE ASS'Y

22

DK534270-8321

DOOR

23

DK534470-9100

LEVER

24

DK580521-6800

CLIP

25

DK592055-0900

CLIP

26

DK536160-2201

ROD

27

DK012514-1640

SCREW

28

DK534189-9200

LINING

29

DK020046-3540

BOLT

30

DK534280-1400

SHAFT

31

DK012153-0640

SCREW
