Запчасти Komatsu PC228USLC-3 ЦИЛИНДР СТРЕЛЫ(YELНИЗ.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XU160

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XU170

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

707-01-0E770

CYLINDER ASS'Y

1

707-13-12290

CYLINDER

2

707-76-70651

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-58-85270

ROD,PISTON

5

707-76-80431

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-12921

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90610

BUSHING

11

707-51-85030

PACKING,ROD (KIT)

12

07000-15110

O-RING (KIT)

13

707-35-91220

RING,BACK-UP (KIT)

14

707-51-85640

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-12851

PISTON

18

707-44-12180

RING,PISTON (KIT)

19

707-39-12140

RING,WEAR (KIT)

20

707-44-12911

RING

21

07000-15075

O-RING (KIT)

22

707-35-90930

RING,BACK-UP (KIT)

23

01310-01216

SCREW

24

707-86-66730

TUBE,L.H.

24

707-86-66740

TUBE,R.H.

25

20Y-62-24580

TUBE,L.H.

25

20Y-62-24610

TUBE,R.H.

26

01435-01055

BOLT

27

01435-01040

BOLT

28

07000-13030

O-RING (KIT)

29

707-88-22550

BRACKET,L.H.

29

707-88-22560

BRACKET,R.H.

30

707-88-21251

BAND

31

01435-01030

BOLT

32

07283-32738

CLIP

33

01597-01009

NUT

34

01643-31032

WASHER

|$44

707-99-46130

SERVICE KIT
