Запчасти Komatsu PC228USLC-3 ГИДР. БАК. (БАК) (YELНИЗ.) (ДЛЯ ПОДЪЕМА РУКОЯТИ)(№-) ГИДРАВЛИКА

1

22U-60-21111YN

TANK

2

203-60-31100

ELBOW ASS'Y

3

203-60-31160

TUBE

4

07230-20628

UNION

5

07002-12434

O-RING

6

07235-10522

ELBOW

7

07002-12434

O-RING

8

07230-20210

UNION

9

07002-11423

O-RING

10

207-60-71182

ELEMENT

10

207-60-71181

ELEMENT

10

207-60-71180

ELEMENT

11

20Y-60-31140

STRAINER

12

20Y-60-31131

VALVE ASS'Y

13

20Y-60-21240

SPRING

14

22U-60-21231YN

COVER

15

07000-15160

O-RING

16

01010-81230

BOLT

17

01643-31232

WASHER

|$33

22U-60-21171

STRAINER ASS'Y

18

22U-60-21181

ROD ASS'Y

19

20Y-60-21320

HOLDER

20

12R-60-11230

SPRING

21

22B-60-11160

STRAINER

22

22U-60-21221YN

COVER

23

07000-15195

O-RING

24

01010-81230

BOLT

25

01643-31232

WASHER

26

17A-60-11310

CAP ASS'Y

27

20Y-60-21470

ELEMENT

28

208-60-71180YN

NECK

28

20Y-60-21460YN

NECK

29

20Y-60-21340

GASKET

30

01252-70516

BOLT

31

01601-20513

WASHER

32

07285-00155

CLIP

33

07270-61415

TUBE

34

04434-51812

CLIP

35

01010-81220

BOLT

36

01643-31232

WASHER

37

205-00-73360

PLATE, OPERATING
