Запчасти Komatsu PC228USLC-3 КАПОТ (YELНИЗ.)(№-) ЧАСТИ КОРПУСА

|$2

22U-54-21144

HOOD

1

HOOD

2

22U-54-23570

HINGE (WELDED)

3

198-54-41982

LOCK ASS'Y (WELDED)

4

22U-54-23731

SHEET

5

22U-54-21131

SHEET

6

22U-54-21161

SEAL

7

01010-81230

BOLT

8

01643-31232

WASHER

9

22U-54-23461

FRAME

10

01010-81225

BOLT

11

01643-31232

WASHER

12

01010-81230

BOLT

13

01643-31232

WASHER

14

22U-54-23561

FRAME

15

01010-81230

BOLT

16

01643-31232

WASHER

17

22U-54-23551

FRAME

18

01010-81225

BOLT

19

01643-31232

WASHER

20

22U-54-23423

FRAME

21

22U-54-21840

BAR

22

01643-31032

WASHER

23

04050-13018

PIN

24

205-54-51970

DOVE TAIL

25

01010-80612

BOLT

26

01643-30623

WASHER

27

205-54-53550

DOVE TAIL

28

01010-80616

BOLT

29

01643-30623

WASHER

30

22U-54-21150

BRACKET

31

01010-81230

BOLT

32

01643-31232

WASHER

33

20Y-54-28182

PLATE

34

01010-81230

BOLT

35

01643-31232

WASHER

36

22U-54-21170

BRACKET

37

01010-81230

BOLT

38

01643-31232

WASHER

39

22U-54-23720

SHEET

40

01010-81230

BOLT

41

01643-31232

WASHER
