Артикул
Название
Примечание
Количество
G-1
22U-63-X9240
CYLINDER GROUP,L.H. (STRATO BLUE)
G-2
22U-63-X9250
CYLINDER GROUP,R.H. (STRATO BLUE)
|1
22U-63-02603
CYLINDER ASS'Y
1
22U-63-52543
CYLINDER
2
20Y-70-21230
BUSHING
3
07145-00070
SEAL,DUST (KIT)
4
22U-63-52521
ROD,PISTON
5
20Y-70-21360
BUSHING
6
07145-00080
SEAL,DUST (KIT)
7
707-27-12921
HEAD,CYLINDER
8
07179-13099
RING,SNAP
9
707-56-85510
SEAL,DUST (KIT)
10
707-52-90610
BUSHING
11
707-51-85030
PACKING,ROD (KIT)
12
07000-15110
O-RING (KIT)
13
707-35-91220
RING,BACK-UP (KIT)
14
707-51-85640
RING,BUFFER (KIT)
15
01010-81670
BOLT
16
01643-51645
WASHER
17
707-36-12071
PISTON
18
707-44-12180
RING,PISTON (KIT)
19
707-39-12110
RING,WEAR (KIT)
20
707-44-12911
RING
21
07000-15075
O-RING (KIT)
22
707-35-90930
RING,BACK-UP (KIT)
23
01310-01216
SCREW
24
22U-63-52572
TUBE,L.H.
|24
22U-63-52672
TUBE,R.H.
25
20Y-62-24580
TUBE,L.H.
|25
20Y-62-24610
TUBE,R.H.
26
01435-01055
BOLT
27
01435-01040
BOLT
28
07000-13030
O-RING (KIT)
29
22U-63-52590
BRACKET,L.H.
|29
22U-63-52690
BRACKET,R.H.
30
707-88-21250
BAND
31
01010-81035
BOLT
32
01643-51032
WASHER
33
07283-22738
CLIP
34
01599-01011
NUT
35
01643-31032
WASHER
|36
707-99-46140
SERVICE KIT
Выбрано товаров: 42
