Запчасти Komatsu PC228USLC-3-AA ЦИЛИНДР СТРЕЛЫ(BLUE)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

22U-63-X9240

CYLINDER GROUP,L.H. (STRATO BLUE)

G-2

22U-63-X9250

CYLINDER GROUP,R.H. (STRATO BLUE)

|1

22U-63-02603

CYLINDER ASS'Y

1

22U-63-52543

CYLINDER

2

20Y-70-21230

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

22U-63-52521

ROD,PISTON

5

20Y-70-21360

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-12921

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90610

BUSHING

11

707-51-85030

PACKING,ROD (KIT)

12

07000-15110

O-RING (KIT)

13

707-35-91220

RING,BACK-UP (KIT)

14

707-51-85640

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-12071

PISTON

18

707-44-12180

RING,PISTON (KIT)

19

707-39-12110

RING,WEAR (KIT)

20

707-44-12911

RING

21

07000-15075

O-RING (KIT)

22

707-35-90930

RING,BACK-UP (KIT)

23

01310-01216

SCREW

24

22U-63-52572

TUBE,L.H.

|24

22U-63-52672

TUBE,R.H.

25

20Y-62-24580

TUBE,L.H.

|25

20Y-62-24610

TUBE,R.H.

26

01435-01055

BOLT

27

01435-01040

BOLT

28

07000-13030

O-RING (KIT)

29

22U-63-52590

BRACKET,L.H.

|29

22U-63-52690

BRACKET,R.H.

30

707-88-21250

BAND

31

01010-81035

BOLT

32

01643-51032

WASHER

33

07283-22738

CLIP

34

01599-01011

NUT

35

01643-31032

WASHER

|36

707-99-46140

SERVICE KIT
