Запчасти Komatsu PC228USLC-2J ОСНОВН. КОНСТРУКЦИЯ (КОНТРОЛЬ ХОДА) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

702-16-01541

PILOT VALVE

1

702-16-01540

PILOT VALVE

2

01010-81025

BOLT

3

01643-31032

WASHER

4

20Y-43-21151

COVER

5

01010-D1025

BOLT

6

20Y-43-21260

COLLAR

7

203-54-56970

WASHER

8

203-43-51620

SPRING

9

20Y-43-21140

COVER

10

22U-43-21150

LEVER

11

01010-D1045

BOLT

12

01643-71032

WASHER

13

01010-81030

BOLT

14

01643-31032

WASHER

15

22U-43-21111

PEDAL,L.H.

16

22U-43-21121

PEDAL,R.H.

17

20Y-43-21161

PLATE

18

01010-D1025

BOLT

19

01643-71032

WASHER

20

22U-43-21130

LEVER,L.H.

21

22U-43-21140

LEVER,R.H.

22

20Y-43-21231

KNOB,L.H.

23

20Y-43-21241

KNOB,R.H.

24

01023-20416

SCREW

25

702-16-53240

PLUG

26

07000-12018

O-RING

27

07235-10210

ELBOW

28

07002-11423

O-RING

29

20Y-62-16170

BOLT

30

07000-12015

O-RING

31

20T-910-8521

HOSE

32

203-62-52410

HOSE, 500MM

33

08034-00536

BAND

34

22U-62-12570

HOSE, 400MM

35

22U-62-12580

HOSE, 450MM

36

22U-62-12560

HOSE, 500MM

37

20Y-62-22790

BAND, RED,RED

38

20Y-62-22820

BAND, BLUE,BLUE

39

20Y-62-22850

BAND, GREEN,GREEN

40

20Y-62-22860

BAND, BROWN,BROWN

41

203-62-62631

HOSE, 450MM

42

07230-20210

UNION

43

07002-11423

O-RING
