Запчасти Komatsu PC228USLC-2 ЦИЛИНДР РУКОЯТИ(№9-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XX910

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0E570

CYLINDER ASS'Y

1

205-63-61142

CYLINDER

2

707-76-80010

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-95190

ROD,PISTON

5

707-27-13961

HEAD,CYLINDER

6

07179-13109

RING,SNAP

7

707-56-95510

SEAL,DUST (KIT)

8

707-52-90720

BUSHING

9

707-51-95030

PACKING,ROD (KIT)

10

07000-15125

O-RING (KIT)

11

707-35-91370

RING,BACK-UP (KIT)

12

707-51-95630

RING,BUFFER (KIT)

13

01010-81875

BOLT

14

707-41-11840

WASHER

15

707-36-13731

PISTON

16

707-44-13280

RING,PISTON (KIT)

17

707-39-13510

RING,WEAR (KIT)

18

707-44-13920

RING

19

707-71-61040

PLUNGER

20

07000-15085

O-RING (KIT)

21

707-35-90960

RING,BACK-UP (KIT)

22

01310-01216

SCREW

23

707-71-60230

PLUNGER

24

07020-00900

FITTING,GREASE

25

707-71-32770

COLLAR

26

707-35-91370

RING,BACK-UP (KIT)

27

07000-15125

O-RING (KIT)

28

04260-00635

BALL

29

707-71-91270

CAP

30

707-83-13010

VALVE

31

07750-01628

SPRING

32

707-87-14070

PLUG

33

07002-12034

O-RING (KIT)

34

205-63-61171

TUBE

35

20D-62-17860

ELBOW

36

01435-01055

BOLT

37

01435-01040

BOLT

38

07000-13030

O-RING (KIT)

39

01010-81080

BOLT

40

01643-31032

WASHER

41

07000-13035

O-RING (KIT)

42

707-88-95341

BRACKET

43

707-88-95320

BAND

44

01010-81035

BOLT

45

01643-51032

WASHER

46

707-88-11560

PLATE

47

07283-22738

CLIP

48

01599-01011

NUT

49

01643-31032

WASHER
