Запчасти Komatsu PC228USLC-1-TN КАБИНА (СДВИГ. ВВЕРХ ОКНА)(№8-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC228USLC-1-TN - КАБИНА (СДВИГ. ВВЕРХ ОКНА)(№8-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
4
5
5
6
7
8
9
10
11
12
13
14
15
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
31A
32
33
34
35
36
37
38
39
40
41
42
42
43
44
45
46
47
47
48
48
49
49
50
51
52
53

Артикул

Название

Примечание

Количество

|1

22U-54-00031

OPERATOR'S CAB ASS'Y,(MANUAL WINDOW)

|1

22U-54-00030

OPERATOR'S CAB ASS'Y,(MANUAL WINDOW)

|1

22U-54-00041

OPERATOR'S CAB ASS'Y,(WITH HEAD GUARD)

|1

22U-54-00040

OPERATOR'S CAB ASS'Y,(WITH HEAD GUARD)

|1

22U-54-00051

OPERATOR'S CAB ASS'Y,(WITH DOOR SASH)

|1

22U-54-00050

OPERATOR'S CAB ASS'Y,(WITH DOOR SASH)

|1

22U-54-00061

OPERATOR'S CAB ASS'Y,(MANUAL WINDOW) (FOR NZ)

|1

22U-54-00060

OPERATOR'S CAB ASS'Y,(MANUAL WINDOW) (FOR NZ)

|1

22U-54-00071

OPERATOR'S CAB ASS'Y,(MANUAL WINDOW) (FOR U.S.A.)

|1

22U-54-00070

OPERATOR'S CAB ASS'Y,(MANUAL WINDOW) (FOR U.S.A.)

|1

22U-54-00081

OPERATOR'S CAB ASS'Y,(WITH HEAD GUARD) (FOR U.S.A.)

|1

22U-54-00080

OPERATOR'S CAB ASS'Y,(WITH HEAD GUARD) (FOR U.S.A.)

1

22U-54-14310

WINDOW,FRONT

2

22M-54-14540

LATCH ASS'Y,L.H.

3

22M-54-14550

LATCH ASS'Y,R.H.

4

20Y-54-14750

BOLT

5

01643-70823

WASHER

6

20Y-54-14310

STRIKER

7

20Y-54-14280

SCREW

8

20Y-54-14290

STOPPER

9

20T-54-74550

NUT

10

21J-54-14541

SEAL

11

21J-54-14551

PLATE

12

01370-40416

SCREW

13

22U-54-14321

GLASS,FRONT

14

21J-54-14530

DAM

15

20T-54-74230

ROLLER¤ 26.0MM

16

21W-54-24821

MOTOR ASS'Y

17

01010-D1016

BOLT

18

01643-71032

WASHER

19

20U-54-24840

ARM

|19

20U-54-24840

ARM

20

22B-54-14370

BLADE

|20

20T-54-74990

BLADE

21

22U-54-14381

COVER

22

08034-20876

BAND

23

21W-54-14690

CLIP

24

14X-911-4551

CLIP

25

22B-54-14670

BRACKET

26

01010-D0816

BOLT

27

01643-70823

WASHER

28

205-54-63310

LOCK ASS'Y

29

01010-D0816

BOLT

30

01643-70823

WASHER

31

22U-54-14970

STOPPER

31A

22U-54-14670

STOPPER

|31A

22U-54-14970

STOPPER

32

01240-00825

SCREW

33

21J-54-14650

SEAL,FRONT

34

01583-11811

NUT

35

21J-06-12440

SWITCH

36

569-06-61960

RELAY

37

287-06-16420

BRACKET

38

01435-40608

BOLT

39

22U-54-14541

GLASS,FRONT¤ LOWER

40

20U-54-24611

LATCH,L.H.

41

20U-54-24621

LATCH,R.H.

42

20T-54-32750

PACKING¤ 2.0MM

43

20T-54-32870

PACKING¤ 1.0MM

44

20T-54-32760

RETAINER,L.H.

45

20T-54-32770

RETAINER,R.H.

46

20T-54-32780

PACKING

47

01023-20510

SCREW

48

20U-54-25140

STOPPER

49

22U-54-14890

BRACKET

50

20T-54-75210

GROMMET

51

01435-40612

BOLT

52

22U-54-14870

BRACKET,REAR

53

01435-40612

BOLT

Выбрано товаров: 69
