Запчасти Komatsu PC228USLC-1 TRAVAL МОТОР (МОТОР В СБОРЕ) (GM8VL ТИП) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

22U-60-12510

MOTOR

|$2

TZ695B1000-00

FINAL DRIVE ASS'Y

1

TZ684B1001-01

HUB

1

TZ684B1102-02

SPINDLE KIT

1

TZ684B1132-02

SPINDLE ASS'Y

2

SPINDLE

3

FLANGE

4

TZ671B1019-00

BOLT

5

PIN

6

WASHER

|$11

TZ695B1104-00

RV GEAR ASS'Y

|$12

RV GEAR KIT

7

RV GEAR

8

RV GEAR

9

SHAFT

10

SPACER

11

BEARING

12

BEARING

13

TZ671B1006-01

GEAR

|$20

TZ671B1107-01

SPUR GEAR KIT

14

SPUR GEAR

15

TZ671B1008-03

COVER

16

TZ671B1013-02

PIECE

17

TZ50F1024-00

COUPLING

18

TZ671B1017-00

PIN

19

04065-09530

RING

20

TZ671B1021-00

BEARING

21

04064-04018

RING

22

07000-11008

O-RING (K1)

23

07000-05230

O-RING (K1)

24

07000-05335

O-RING (K1)

25

170-27-00024

FLOATING SEAL ASS'Y

25

170-27-00114

SEAL RING ASS'Y (K1)

25

RING

25

RING

25

170-27-00120

O-RING ASS'Y

25

O-RING

26

TZ610B2021-00

PLUG

27

TZJB1176M12-32

BOLT

28

04260-01111

BALL

29

TZ671B2077-01

PIN

30

07000-12018

O-RING (K1)
