Запчасти Komatsu PC228USLC-1 ОХЛАЖД-Е (РАДИАТОР И ТРУБЫ) СИСТЕМА ОХЛАЖДЕНИЯ

1

206-03-61610

RADIATOR CORE ASS'Y

2

20Y-03-22110

CAP

3

20Y-03-21980

PLUG

4

07000-11007

O-RING

4

07000-01007

O-RING

5

363-03-11150

TUBE

6

20Y-03-11330

CLIP

7

22U-03-11520

OIL COOLER ASS'Y

8

22U-03-11560

COVER

9

22U-03-11370

SHEET

10

01434-10616

BOLT, WING

11

01643-30823

WASHER

12

01010-81225

BOLT

13

01643-31232

WASHER

14

22U-03-11340

SHEET

15

22U-03-11350

SHEET

16

22U-03-11360

SHEET

17

22U-03-11580

NET

18

22U-03-11590

NET

19

22U-03-11380

SEAL

20

01434-10616

BOLT, WING

21

01643-30823

WASHER

22

22U-03-11450

SEAL

23

22U-03-11530

SHROUD

24

01435-20816

BOLT

25

20Y-03-14110

SEAL

26

22U-979-1110

BRACKET

27

01010-81025

BOLT

28

01643-31032

WASHER

29

22U-979-1510

BRACKET

30

01010-81025

BOLT

31

01643-31032

WASHER

32

22U-03-11570

SHEET

33

22U-03-11431

SHEET

34

22U-03-11441

SHEET

35

22U-03-11461

SHEET

36

22U-03-11471

SHEET

37

22U-03-11221

HOSE

38

07289-00055

CLAMP

39

22U-03-11540

HOSE

40

07289-00055

CLAMP

41

07289-00070

CLAMP

42

208-62-38370

CLIP

43

01010-81080

BOLT

44

01643-31032

WASHER

45

6204-81-9560

SPACER
