Запчасти Komatsu PC228USLC-1 SLIDE ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

205-63-X7180

CYLINDER GROUP

|1

205-63-07180

CYLINDER ASS'Y

1

205-63-93541

CYLINDER

2

07143-10505

BUSHING

3

07145-00050

SEAL,DUST (KIT)

4

205-63-93520

ROD,PISTON

5

07143-10505

BUSHING

6

07145-00050

SEAL,DUST (KIT)

7

707-27-95620

HEAD,CYLINDER

8

07179-12079

RING,SNAP

9

144-63-92170

SEAL,DUST (KIT)

10

707-52-90400

BUSHING

11

707-51-65030

PACKING,ROD (KIT)

12

707-51-65630

RING,BUFFER (KIT)

13

707-71-32330

COLLAR

14

07000-15090

O-RING (KIT)

15

07001-05090

RING,BACK-UP (KIT)

16

01010-81465

BOLT

17

705-17-04980

WASHER

18

707-71-60681

PLUNGER

19

707-41-10580

WASHER

20

707-36-90300

PISTON

21

707-44-90180

RING,PISTON (KIT)

22

707-39-90110

RING,WEAR (KIT)

23

707-44-90911

RING

24

707-71-60100

PLUNGER

25

04260-00635

BALL

26

707-71-91280

CAP

27

07165-04244

NUT

28

707-88-60120

PIN

29

707-88-17440

ROLLER

30

01643-51645

WASHER

31

04050-14028

PIN,COTTER

32

205-63-93570

TUBE

33

205-63-93580

TUBE

34

01010-50855

BOLT

35

01010-50840

BOLT

36

01010-50830

BOLT

37

01643-30823

WASHER

38

07000-13030

O-RING (KIT)

39

707-88-13590

CLAMP

40

01010-51040

BOLT

41

01643-31032

WASHER

|42

707-98-28700

SERVICE KIT
