Запчасти Komatsu PC228US-8 ПЕРЕГОРОДКА. COVER, КРЫШКА(/) (№-) ПЕРЕГОРОДКА. COVER, СТРЕЛА ANTI-DROP КЛАПАН, РАЗРУШ. ЗДАНИЙ СПЕЦ-ЯIFICATION

1

01010-81230

Bolt

2

01643-31232

Washer

3

205-54-76411

Collar

4

22U-54-22680

Plate

5

01010-81230

Bolt

6

01643-31232

Washer

7

205-54-76411

Collar

7

22U-54-35210

Cover

8

Cover

9

22U-54-11960

Seal

10

01010-81230

Bolt

11

01643-31232

Washer

11

22U-54-33670

Cover

12

Cover

13

22U-54-33690

Sheet

14

124-A62-1920

Cap

15

22U-54-32680

Seal

16

22U-54-32690

Seal

17

01010-81230

Bolt

18

01643-31232

Washer

19

22U-54-35640

Bracket Assembly

|$21

22U-54-32981

Bracket

20

21M-00-21280

Plate

21

21M-00-21290

Plate

22

22U-54-32660

Plate

23

01010-81230

Bolt

24

01643-31232

Washer

|$27

22U-54-32911

Cover Assembly

25

Cover

26

22U-54-32930

Sheet

27

01643-51232

Washer

28

124-54-26540

Washer

29

01010-81230

Bolt

30

22U-54-32941

Sheet

31

22U-54-33950

Sheet

32

01010-81230

Bolt

33

01643-31232

Washer

33

22U-54-32961

Cover Assembly

34

Cover

35

22U-54-32990

Sheet

36

01643-51232

Washer

37

124-54-26540

Washer

38

01010-81220

Bolt

39

01010-81230

Bolt

40

01643-31232

Washer

40

22U-54-33911

Bracket Assembly

41

Bracket

42

203-54-63230

Clamp

43

01023-20614

Screw

44

01010-81230

Bolt

45

01643-31232

Washer

45

22U-54-34770

Cover Assembly

46

Cover

47

22U-54-34790

Sheet

48

124-A62-1920

Cap

49

01010-81230

Bolt

50

01643-31232

Washer
