Запчасти Komatsu PC228US-8 ГИДР. БАК., (№-) ГИДР. БАК., С РУКОЯТЬ CRANE, -НАВЕСН. ОБОРУД

1

22U-60-31111

Tank

2

203-60-31100

Elbow Assembly

3

203-60-31160

Tube

4

02783-10628

Elbow

5

07002-12434

O-ring

6

02896-11018

O-ring

7

02782-10522

Elbow

8

07002-12434

O-ring

9

02896-11015

O-ring

10

207-62-61680

Tee

11

07002-11423

O-ring

12

02781-0021D

Union

13

07002-11423

O-ring

14

02896-11008

O-ring

15

207-60-71182

Element, Hydraulic Oil Filter

16

20Y-60-31140

Strainer

17

20Y-60-31131

Valve Assembly

18

20Y-60-21240

Spring

19

22U-60-21232

Cover

20

07000-15195

O-ring

21

01010-81230

Bolt

22

01643-31232

Washer

|$22

22U-60-21171

Strainer Assembly

23

22U-60-21181

Rod Assembly

24

20Y-60-21320

Holder

25

12R-60-11230

Spring

26

22B-60-11160

Strainer

27

22U-60-21223

Cover

28

07000-15160

O-ring

29

01010-81230

Bolt

30

01643-31232

Washer

31

22U-60-31120

Cap Assembly

32

20Y-60-21470

Element

33

208-60-71181

Filler Neck

34

20Y-60-21340

Gasket

35

01252-A0516

Bolt, Hexagon Socket Head

36

01601-20513

Washer

37

07285-00220

Clip

38

22U-60-31150

Hose

39

04434-52312

Clip

40

01010-81220

Bolt

41

01643-31232

Washer

42

205-00-73360

Plate, Operating

43

22U-60-27151

Sheet

44

22U-60-31141

Sheet
