Запчасти Komatsu PC228US-8 ГИДР. БАК. (№-) ГИДР. БАК., БЕЗ -ДОПОЛН. АКТУАТОР ТРУБЫ, АККУМУЛЯТОР

1

22U-60-31111

Tank

2

203-60-31100

Elbow Assembly

3

203-60-31160

Tube

4

02783-10628

Elbow

5

07002-12434

O-ring

6

02896-11018

O-ring

7

02782-10522

Elbow

8

07002-12434

O-ring

9

02896-11015

O-ring

10

02783-10315

Elbow

11

07002-12034

O-ring

12

02896-11009

O-ring

13

11Y-62-12510

Elbow

14

07002-11423

O-ring

15

02896-11009

O-ring

16

07040-12412

Plug

17

07002-12434

O-ring

18

02782-10315

Elbow

19

07002-12034

O-ring

20

02896-11009

O-ring

21

07040-11409

Plug

22

07002-11423

O-ring

23

207-60-71182

Element, Hydraulic Oil Filter

24

20Y-60-31140

Strainer

25

20Y-60-31131

Valve Assembly

26

20Y-60-21240

Spring

27

22U-60-21232

Cover

28

07000-15195

O-ring

29

01010-81230

Bolt

30

01643-31232

Washer

|$30

22U-60-21171

Strainer Assembly

31

22U-60-21181

Rod Assembly

32

20Y-60-21320

Holder

33

12R-60-11230

Spring

34

22B-60-11160

Strainer

35

22U-60-21223

Cover

36

07000-15160

O-ring

37

01010-81230

Bolt

38

01643-31232

Washer

39

22U-60-31120

Cap Assembly

40

20Y-60-21470

Element

41

208-60-71181

Filler Neck

42

20Y-60-21340

Gasket

43

01252-A0516

Bolt, Hexagon Socket Head

44

01601-20513

Washer

45

07285-00220

Clip

46

22U-60-31150

Hose

46

07261-21415

Hose

47

04434-52312

Clip

48

01010-81220

Bolt

49

01643-31232

Washer

50

205-00-73360

Plate, Operating

51

22U-60-27151

Sheet

52

22U-60-31141

Sheet
