Запчасти Komatsu PC228US-8 КАБИНА, ПОЛ, 1 УПРАВЛ. НАВЕСН. ОБОРУД. (№-) КАБИНА, ДЛЯ АВСТРАЛИИ

1

22U-43-21470

Seat

2

01010-81025

Bolt

3

01643-31032

Washer

4

20Y-62-25360

Bracket

5

01010-81025

Bolt

6

01643-31032

Washer

7

22B-43-23730

Pedal

8

01010-D1045

Bolt

9

01643-71032

Washer

10

22B-43-23620

Plate

11

01010-81020

Bolt

12

01643-31032

Washer

13

22B-43-23630

Plate

14

22B-43-23650

Sheet

15

01010-81016

Bolt

16

01643-31032

Washer

17

207-43-81240

Cap

18

21W-62-43980

Elbow

19

07000-12011

O-ring

20

02896-11008

O-ring

21

21W-62-43990

Elbow

22

20T-910-8660

Nipple

23

22B-62-25650

Elbow

24

206-06-61130

Switch, Pressure

25

22B-06-21590

Wiring Harness

26

08034-20536

Band

27

20Y-62-22810

Band, Yellow

28

22U-62-31190

Hose

29

22B-62-25320

Hose

30

20Y-62-51910

Hose

31

01583-51408

Nut

32

04434-51810

Clip

33

01010-81016

Bolt

34

01643-31032

Washer

35

07095-20213

Cushion
