Запчасти Komatsu PC228US-8 ЦИЛИНДР СТРЕЛЫ, ПРАВ. (№-) ЦИЛИНДР СТРЕЛЫ, БЕЗ ANTI-DROP КЛАПАН

|$0

707-01-0CE10

Cylinder Group

1

707-13-12960

Cylinder

2

707-58-85480

Rod

3

707-76-70651

Bushing

4

07145-00070

Seal, Dust, (Kit : K04)

5

707-76-80431

Bushing

6

07145-00080

Seal, Dust, (Kit : K04)

7

707-27-12650

Head, Cylinder

8

707-56-85740

Seal, Dust, (Kit : K04)

9

07179-13099

Ring, Snap

10

707-51-85030

Packing, Rod, (Kit : K04)

11

707-51-85650

Ring, Buffer, (Kit : K04)

12

707-52-90611

Bushing

13

707-35-91220

Ring, Back-up, (Kit : K04)

14

07000-15110

O-ring, (Kit : K04)

15

01010-81670

Bolt

16

01643-51645

Washer

17

707-75-85110

Ring, Snap

18

707-36-12851

Piston

19

707-44-12150

Ring, Piston, (Kit : K04)

20

707-39-12140

Ring, Wear, (Kit : K04)

21

707-44-12911

Ring

22

07000-15075

O-ring, (Kit : K04)

23

707-35-90930

Ring, Back-up, (Kit : K04)

24

01310-01216

Screw

25

707-86-68880

Tube,R.H.

26

707-86-68900

Tube,R.H.

27

707-88-28020

Bracket,R.H.

28

07372-21060

Bolt

29

01643-51032

Washer

30

07372-21045

Bolt

31

01643-51032

Washer

32

707-88-21620

Band

33

07000-13030

O-ring, (Kit : K04)

34

07372-21035

Bolt

35

01643-51032

Washer

36

07283-32738

Clip, Pipe

37

01597-01009

Nut

38

01643-31032

Washer
