Запчасти Komatsu PC228US-3T-YT ЦИЛИНДР КОВША (ТУННЕЛЬН. СПЕЦ-Я.) (YELНИЗ.)(№8-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XU251

CYLINDER GROUP,(FINAL COATING)

|1

707-01-0E861

CYLINDER ASS'Y

1

707-13-13611

CYLINDER

2

707-76-80470

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-90940

ROD,PISTON

5

707-76-80480

BUSHING

6

20Y-70-23230

SEAL,DUST (KIT)

7

707-27-13121

HEAD,CYLINDER

8

07179-13104

RING,SNAP

9

195-63-94170

SEAL,DUST (KIT)

10

707-52-90680

BUSHING

11

707-51-90030

PACKING,ROD (KIT)

12

07000-15120

O-RING (KIT)

13

707-35-91320

RING,BACK-UP (KIT)

14

707-51-90640

RING,BUFFER (KIT)

15

01010-81875

BOLT

16

707-41-11840

WASHER

17

707-36-13780

PISTON

18

707-44-13180

RING,PISTON (KIT)

19

707-39-13150

RING,WEAR (KIT)

20

707-44-13911

RING

21

707-35-90940

RING,BACK-UP (KIT)

22

07000-15080

O-RING (KIT)

23

01310-01216

SCREW

24

07020-00000

FITTING,GREASE

25

07020-00900

FITTING,GREASE

26

707-86-66721

TUBE

27

01435-01055

BOLT

28

01435-01040

BOLT

29

07000-13030

O-RING (KIT)

30

707-88-22640

BRACKET

31

707-88-21331

BAND

32

01435-01030

BOLT

33

07283-32738

CLIP

34

01597-01009

NUT

35

01643-31032

WASHER

|K

707-99-47570

SERVICE KIT
