Артикул
Название
Примечание
Количество
G-1
707-01-XU220
BOOM CYLINDER GROUP,L.H. (FINAL COATING)
G-2
707-01-XU230
BOOM CYLINDER GROUP,R.H. (FINAL COATING)
|1
707-01-0E770
CYLINDER ASS'Y
1
707-13-12290
CYLINDER
2
707-76-70651
BUSHING
3
07145-00070
SEAL,DUST (KIT)
4
707-58-85270
ROD,PISTON
5
707-76-80431
BUSHING
6
07145-00080
SEAL,DUST (KIT)
7
707-27-12921
HEAD,CYLINDER
8
07179-13099
RING,SNAP
9
707-56-85510
SEAL,DUST (KIT)
10
707-52-90610
BUSHING
11
707-51-85030
PACKING,ROD (KIT)
12
07000-15110
O-RING (KIT)
13
707-35-91220
RING,BACK-UP (KIT)
14
707-51-85640
RING,BUFFER (KIT)
15
01010-81670
BOLT
16
01643-51645
WASHER
17
707-36-12851
PISTON
18
707-44-12180
RING,PISTON (KIT)
19
707-39-12140
RING,WEAR (KIT)
20
707-44-12911
RING
21
07000-15075
O-RING (KIT)
22
707-35-90930
RING,BACK-UP (KIT)
23
01310-01216
SCREW
24
707-86-66730
TUBE,L.H.
|24
707-86-66740
TUBE,R.H.
25
01435-01055
BOLT
26
01435-01040
BOLT
27
07000-13030
O-RING (KIT)
28
707-88-22550
BRACKET,L.H.
|28
707-88-22560
BRACKET,R.H.
29
707-88-21251
BAND
30
01435-01030
BOLT
31
07283-32738
CLIP
32
01597-01009
NUT
33
01643-31032
WASHER
|K
707-99-46130
SERVICE KIT
Выбрано товаров: 39
