Запчасти Komatsu PC228US-3N-YG КАПОТ (YELНИЗ.) ЧАСТИ КОРПУСА

|1

22U-54-21143

HOOD

1

HOOD

2

22U-54-23570

HINGE (WELDED)

3

198-54-41982

LOCK ASS'Y (WELDED)

4

22U-54-23731

SHEET

5

22U-54-21131

SHEET

6

22U-54-21161

SEAL

7

01010-81230

BOLT

8

01643-31232

WASHER

9

22U-54-23461

FRAME

10

01010-81230

BOLT

11

01643-31232

WASHER

12

22U-54-23561

FRAME

13

01010-81230

BOLT

14

01643-31232

WASHER

15

22U-54-23551

FRAME

16

01010-81225

BOLT

17

01643-31232

WASHER

18

22U-54-23423

FRAME

|18

22U-54-23422

FRAME

19

22U-54-21840

BAR

20

01643-31032

WASHER

21

04050-13018

PIN

22

205-54-51970

DOVE TAIL

23

01010-80612

BOLT

24

01643-30623

WASHER

25

205-54-53550

DOVE TAIL

26

01010-80616

BOLT

27

01643-30623

WASHER

28

22U-54-21150

BRACKET

29

01010-81230

BOLT

30

01643-31232

WASHER

31

20Y-54-28182

PLATE

32

01010-81230

BOLT

33

01643-31232

WASHER

34

22U-54-21170

BRACKET

35

01010-81230

BOLT

36

01643-31232

WASHER

37

22U-54-23720

SHEET

38

01010-81230

BOLT

39

01643-31232

WASHER
