Запчасти Komatsu PC228US-3N-YA ОСНОВН. КОНСТРУКЦИЯ (КОНСОЛЬ) (ПРАВ.) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

22U-43-23111

PLATE

2

22U-06-22330

WIRING HARNESS

3

22U-43-23120

BRACKET

4

22U-43-23130

STAY

5

22U-06-22320

COVER

6

22U-43-23140

COVER

7

22U-06-22420

POTENTIOMETER ASS'Y

8

22U-06-22470

KNOB

9

22B-06-11910

SWITCH

|9

20Y-06-24681

SWITCH

10

22U-06-22480

PLATE

11

22U-06-22190

SWITCH

12

22U-06-22290

SWITCH

13

22U-06-22390

SWITCH

14

20Y-06-23920

CLAMP

15

08034-10414

BAND

16

01023-60408

SCREW

|16

01023-60410

SCREW

17

01023-60512

SCREW

18

01023-10508

SCREW

19

01023-10512

SCREW

20

01601-20513

WASHER

21

01023-60620

SCREW

22

01023-70514

SCREW

23

22U-43-23210

COVER

24

22U-06-22370

SWITCH ASS'Y

25

22U-43-23230

COVER

26

22U-43-23241

FRAME

27

22U-43-23251

SHEET

28

22U-43-23290

CLIP

29

08059-00310

CLIP

30

01023-60616

SCREW

31

569-06-61960

RELAY

32

01435-00612

BOLT

33

01023-60410

SCREW

|33

01023-60410

SCREW

34

22U-43-23711

COVER

35

01023-10614

SCREW

36

01643-30623

WASHER

37

01010-D1030

BOLT

38

01643-71032

WASHER
