Запчасти Komatsu PC228US-3E0 БЛОК КОНДИЦИОНЕРА (/) (АВТОМАТИЧ. КОНДИЦ. ВОЗДУХА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

1

22U-979-1730

AIR CONDITIONER A.

1

DK534138-6620

CASE ASS'Y

1

DK534136-9201

CASE

2

DK534190-0500

LINING

3

DK534461-8802

COVER

4

DK536021-6501

WIRING HARNESS

5

DK592024-3100

CLIP

6

DK592022-3700

SCREW

7

DK595327-8100

CLIP

8

DK592022-3700

SCREW

9

DK595327-8100

CLIP

10

DK592022-3700

SCREW

11

DK582623-8500

SENSOR

12

DK580534-0400

CLIP

13

DK534102-6000

BRACKET

14

DK012514-1640

SCREW

15

DK582623-1800

SENSOR

16

DK580529-7000

CLIP

17

DK012155-1440

SCREW

18

DK583032-2300

INSULATOR

19

DK582594-3020

RELAY ASS'Y

19

DK534104-8400

BRACKET

20

DK593111-8800

RELAY

21

DK593230-1420

RELAY

22

DK580140-0600

SCREW

23

DK582670-2501

POWER TRANSISTOR

24

DK012514-1640

SCREW

25

DK534232-2200

SEAL

26

DK502700-2520

HEATER CORE ASS'Y

27

DK580534-4300

CLIP

28

DK592022-3700

SCREW

29

DK524120-1720

PLATE ASS'Y

30

DK534270-8321

DOOR

31

DK534470-9100

LEVER

32

DK580521-6800

CLIP

33

DK592055-0900

CLIP

34

DK536160-2201

ROD

35

DK012514-1640

SCREW

36

DK534189-9200

LINING

37

DK020046-3540

BOLT

38

DK534280-1400

SHAFT

39

DK012153-0640

SCREW
