Запчасти Komatsu PC228US-3E0 ЦИЛИНДР ОТВАЛА ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

22U-63-X9181

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

22U-63-X9191

CYLINDER GROUP,R.H. (FINAL COATING)

1

22U-63-02550

CYLINDER ASS'Y,L.H.

1

22U-63-02560

CYLINDER ASS'Y,R.H.

1

22U-63-92140

CYLINDER,L.H.

1

22U-63-92240

CYLINDER,R.H.

2

707-76-90130

BUSHING

3

07145-00090

SEAL,DUST (KIT)

4

22U-63-92120

ROD,PISTON

5

707-76-10130

BUSHING

6

07145-00100

SEAL,DUST (KIT)

7

707-27-14920

HEAD,CYLINDER

8

07179-13114

RING,SNAP

9

176-63-56170

SEAL,DUST (KIT)

10

707-52-90780

BUSHING

11

707-51-10030

PACKING,ROD (KIT)

12

07000-15130

O-RING (KIT)

13

707-35-91420

RING,BACK-UP (KIT)

14

707-51-10630

RING,BUFFER (KIT)

15

707-88-32230

BRACKET,L.H.

15

707-88-32240

BRACKET,R.H.

16

01010-81875

BOLT

17

707-41-11840

WASHER

18

707-36-14410

PISTON

19

707-44-14180

RING,PISTON (KIT)

20

707-39-14820

RING,WEAR (KIT)

21

707-44-14910

RING

22

707-81-10150

COLLAR

23

07000-15100

O-RING

24

07000-15090

O-RING (KIT)

25

07001-05090

RING,BACK-UP (KIT)

26

01310-01216

SCREW

27

07020-00000

FITTING

28

707-86-68460

TUBE,L.H.

28

707-86-68470

TUBE,R.H.

29

707-86-68480

TUBE,L.H.

29

707-86-68490

TUBE,R.H.

30

07372-21060

BOLT

31

01643-51032

WASHER

32

07372-21045

BOLT

33

01643-51032

WASHER

34

07000-13030

O-RING (KIT)

35

707-88-31520

PLATE

36

07283-32738

CLIP

37

01597-01009

NUT

38

01643-31032

WASHER

39

02896-11015

O-RING (KIT)

KIT

707-99-58390

SERVICE KIT
