Запчасти Komatsu PC228US-3E0 ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XR240

CYLINDER GROUP,(FINAL COATING)

1

707-01-0H600

CYLINDER ASS'Y

1

707-13-13870

CYLINDER

2

707-76-80431

BUSHING

3

707-77-80010

SEAL,DUST (KIT)

4

707-58-95270

ROD,PISTON

5

707-27-13850

HEAD,CYLINDER

6

07179-13109

RING,SNAP

7

707-56-95730

SEAL,DUST (KIT)

8

707-52-90720

BUSHING

9

707-75-95030

RING,SNAP

10

707-51-95030

PACKING,ROD (KIT)

11

07000-15125

O-RING (KIT)

12

707-35-91370

RING,BACK-UP (KIT)

13

707-51-95650

RING,BUFFER (KIT)

14

01010-81875

BOLT

15

707-41-11840

WASHER

16

707-36-13771

PISTON

17

707-44-13250

RING,PISTON (KIT)

18

707-39-13530

RING,WEAR (KIT)

19

707-44-13920

RING

20

707-71-71070

PLUNGER

21

07000-15085

O-RING (KIT)

22

707-35-90960

RING,BACK-UP (KIT)

23

01310-01216

SCREW

24

707-71-80270

PLUNGER

25

07020-00000

FITTING,GREASE

26

707-71-34980

COLLAR

27

707-35-91370

RING,BACK-UP (KIT)

28

07000-15125

O-RING (KIT)

29

04260-00635

BALL

30

707-71-91270

CAP

31

707-83-13010

VALVE

32

07750-01628

SPRING

33

707-87-14070

PLUG

34

07002-12034

O-RING (KIT)

35

707-86-67740

TUBE

36

07372-51060

BOLT

37

01643-51032

WASHER

38

07372-51045

BOLT

39

01643-51032

WASHER

40

07000-13030

O-RING (KIT)

41

707-88-22530

BRACKET

42

707-88-21261

BAND

43

707-88-28030

BRACKET

44

707-88-21261

BAND

45

07372-21035

BOLT

46

01643-51032

WASHER

47

07283-32738

CLIP

48

01597-01009

NUT

49

01643-31032

WASHER

50

707-88-33040

CAP

51

07371-31049

FLANGE

52

07372-21035

BOLT

53

01643-51032

WASHER

54

707-88-33030

CAP

55

07371-30640

FLANGE

56

07372-21035

BOLT

57

01643-51032

WASHER

K

707-98-48610

SERVICE KIT
