Запчасти Komatsu PC228US-3E0 ЦИЛИНДР СТРЕЛЫ(ПРАВ.) (БОЛЬШ. DIAMETER ТИП) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XP890

CYLINDER GROUP,R.H. (FINAL COATING)

1

707-01-0K880

CYLINDER ASS'Y

1

721-13-13030

CYLINDER

2

707-76-80420

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-58-90F60

ROD,PISTON

5

707-76-80431

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-13650

HEAD,CYLINDER

8

07179-13104

RING,SNAP

9

195-63-94170

SEAL,DUST (KIT)

10

707-52-90680

BUSHING

11

707-75-90110

RING,SNAP

12

707-51-90030

PACKING,ROD (KIT)

13

07000-15120

O-RING (KIT)

14

707-35-91320

RING,BACK-UP (KIT)

15

707-51-90650

RING,BUFFER (KIT)

16

01010-81670

BOLT

17

01643-51645

WASHER

18

707-36-13780

PISTON

19

707-44-13150

RING,PISTON (KIT)

20

707-39-13150

RING,WEAR (KIT)

21

707-44-13911

RING

22

07000-15080

O-RING (KIT)

23

707-35-90940

RING,BACK-UP (KIT)

24

01310-01216

SCREW

25

707-86-68260

TUBE,R.H.

26

206-62-64290

TUBE,R.H.

27

07372-21060

BOLT

28

01643-51032

WASHER

29

07372-21045

BOLT

30

01643-51032

WASHER

31

07000-13030

O-RING (KIT)

32

707-88-28060

BRACKET,R.H.

33

707-88-21331

BAND

34

07372-21035

BOLT

35

01643-51032

WASHER

36

07283-32738

CLIP

37

01597-01009

NUT

38

01643-31032

WASHER

KIT

707-98-47740

SERVICE KIT
