Запчасти Komatsu PC228US-3E0 ЦИЛИНДР СТРЕЛЫ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XN030

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XN040

CYLINDER GROUP,R.H. (FINAL COATING)

1

707-01-0K860

CYLINDER ASS'Y

1

707-13-12640

CYLINDER

2

707-76-70651

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-58-85480

ROD,PISTON

5

707-76-80431

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-12650

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90610

BUSHING

11

707-51-85030

PACKING,ROD (KIT)

12

07000-15110

O-RING (KIT)

13

707-35-91220

RING,BACK-UP (KIT)

14

707-51-85650

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-12851

PISTON

18

707-44-12150

RING,PISTON (KIT)

19

707-39-12140

RING,WEAR (KIT)

20

707-44-12911

RING

21

07000-15075

O-RING (KIT)

22

707-35-90930

RING,BACK-UP (KIT)

23

01310-01216

SCREW

24

707-86-68230

TUBE,L.H.

24

707-86-68240

TUBE,R.H.

25

07372-21060

BOLT

26

01643-51032

WASHER

27

07372-21045

BOLT

28

01643-51032

WASHER

29

07000-13030

O-RING (KIT)

30

707-88-28010

BRACKET,L.H.

30

707-88-28020

BRACKET,R.H.

31

707-88-21620

BAND

32

07372-21035

BOLT

33

01643-51032

WASHER

34

07283-32738

CLIP

35

01597-01009

NUT

36

01643-31032

WASHER

KIT

707-98-46300

SERVICE KIT
