Запчасти Komatsu PC228US-3E0 ГИДР. БАК. ( АКТУАТОР) (ДЛЯ ПОДЪЕМА РУКОЯТИ)(№-) ГИДРАВЛИКА

1

22U-60-27211

TANK

2

203-60-31100

ELBOW ASS'Y

3

203-60-31160

TUBE

4

02781-00628

UNION

5

07002-12434

O-RING

6

02896-11018

O-RING

7

02782-10522

ELBOW

8

07002-12434

O-RING

9

02896-11015

O-RING

10

11Y-62-12330

ELBOW

11

07002-11423

O-RING

12

02896-11008

O-RING

13

207-60-71182

ELEMENT

13

207-60-71181

ELEMENT

14

20Y-60-31140

STRAINER

15

20Y-60-31131

VALVE ASS'Y

16

20Y-60-21240

SPRING

17

22U-60-21232

COVER

18

07000-15160

O-RING

19

01010-81230

BOLT

20

01643-31232

WASHER

|$34

22U-60-21171

STRAINER ASS'Y

21

22U-60-21181

ROD ASS'Y

22

20Y-60-21320

HOLDER

23

12R-60-11230

SPRING

24

22B-60-11160

STRAINER

25

22U-60-21223

COVER

26

07000-15195

O-RING

27

01010-81230

BOLT

28

01643-31232

WASHER

29

17A-60-11310

CAP ASS'Y

30

20Y-60-21470

ELEMENT

31

208-60-71180

FILLER NECK

32

20Y-60-21340

GASKET

33

01252-70516

BOLT

34

01601-20513

WASHER

35

07285-00155

CLIP

36

07270-61415

TUBE

37

04434-51812

CLIP

38

01010-81220

BOLT

39

01643-31232

WASHER

40

07042-70617

PLUG

40

07042-00617

PLUG

41

205-00-73360

PLATE, OIL LEVEL
