Запчасти Komatsu PC228US-3E0 ВЕРХН. ЧАСТЬ (ПРЕФИЛЬТР) (С NET)(№-) ЧАСТИ КОРПУСА

|$1

22U-54-31951

COVER

1

COVER

2

22U-54-87290

SHEET

|$5

423-U12-3101

PRECLEANER ASS'Y

3

HOOD

4

423-U12-3330

BODY

5

421-U12-3140

CLAMP

6

423-U12-3350

ROTOR

7

421-U12-3160

BOLT

8

421-U12-3170

RING

9

421-U12-3181

BEARING

10

421-U12-3190

BUSHING

11

418-U12-3410

BUSHING

12

418-U12-3420

SHIELD

13

421-U12-3230

NUT

14

421-U12-3240

BOLT

15

421-U12-3250

NUT

16

421-U12-3260

PLUG

17

418-U12-3470

WASHER

18

22U-54-21930

BRACKET

19

01010-81225

BOLT

20

01643-51232

WASHER

21

01010-81230

BOLT

22

01643-31232

WASHER

23

22U-54-21920

BRACKET

24

01010-81225

BOLT

25

01643-31232

WASHER

26

01010-81225

BOLT

27

01643-51232

WASHER

28

22U-54-31850

COLLAR

29

01010-81235

BOLT

30

01643-31232

WASHER

31

22U-54-31280

NET

32

01010-80616

BOLT

33

01643-30623

WASHER

34

01643-30623

WASHER

35

01508-10605

NUT

36

20Y-54-75230

COVER

37

22U-54-86590

NET

38

22U-54-86611

NET

39

01010-80616

BOLT

40

01643-30623

WASHER

41

22U-54-21940

SEAL
