Запчасти Komatsu PC228US-3-YG МЕХАНИЗМ ПОВОРОТА(№-) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

706-7G-01011

MOTOR ASS'Y

|1

706-7G-01010

MOTOR ASS'Y

2

22U-26-21280

RING

3

07042-00312

PLUG

4

22U-26-21190

CASE

5

07029-00000

VALVE

6

20Y-26-22330

BEARING

7

22U-26-21340

BEARING

8

22U-26-21560

SHAFT¤ 15 TEETH

9

07012-00115

SEAL

10

22U-26-21270

SPACER

11

07000-15310

O-RING

12

22U-26-21580

CARRIER

13

22U-26-21540

GEAR

14

20G-26-11240

BEARING

15

20Y-27-21240

WASHER

16

20Y-26-22250

PIN

17

20Y-27-21280

PIN

18

20Y-26-21240

PLATE

19

112-32-11211

BOLT¤ SHOE

20

22U-26-21551

GEAR

|20

22U-26-21550

GEAR

21

20K-22-11190

O-RING

22

01010-81440

BOLT

|22

01010-81435

BOLT

22A

01643-31445

WASHER

23

22U-26-21530

GEAR

24

22U-26-21570

CARRIER

25

22U-26-21520

GEAR

26

20Y-26-21281

BEARING

27

22U-26-21230

WASHER,THRUST

28

22U-26-21210

PIN

29

04064-03515

RING

30

22U-26-21250

WASHER,THRUST

31

22U-26-21510

GEAR

32

195-03-13241

VALVE

33

205-26-71620

TUBE

34

07281-00197

CLAMP

35

01010-81035

BOLT

36

01643-51032

WASHER

37

22U-26-21410

TUBE

38

22U-26-21420

FILLER

39

22U-26-21430

GAUGE

40

22U-26-21440

BRACKET

41

22U-26-21450

BRACKET

42

22U-26-21460

CAP

43

07238-10630

CONNECTOR

44

07283-32738

CLIP

45

04434-51710

CLIP

46

01597-01009

NUT

47

01010-81030

BOLT

48

01010-81025

BOLT

49

01643-31032

WASHER

50

07000-15240

O-RING

51

01010-82060

BOLT

52

01643-32060

WASHER
