Запчасти Komatsu PC228US-3-YB ЦИЛИНДР ОТВАЛА(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

22U-63-X9180

CYLINDER GROUP,L.H.

G-2

22U-63-X9190

CYLINDER GROUP,R.H.

|1

22U-63-02550

CYLINDER ASS'Y,L.H.

|1

22U-63-02560

CYLINDER ASS'Y,R.H.

1

22U-63-92140

CYLINDER,L.H.

|1

22U-63-92240

CYLINDER,R.H.

2

707-76-90130

BUSHING

3

07145-00090

SEAL,DUST (KIT)

4

22U-63-92120

ROD,PISTON

5

707-76-10130

BUSHING

6

07145-00100

SEAL,DUST (KIT)

7

707-27-14920

HEAD,CYLINDER

8

07179-13114

RING,SNAP

9

176-63-56170

SEAL,DUST (KIT)

10

707-52-90780

BUSHING

11

707-51-10030

PACKING,ROD (KIT)

12

07000-15130

O-RING (KIT)

13

707-35-91420

RING,BACK-UP (KIT)

14

707-51-10630

RING,BUFFER (KIT)

15

707-88-32230

BRACKET,L.H.

|15

707-88-32240

BRACKET,R.H.

16

01010-81875

BOLT

17

707-41-11840

WASHER

18

707-36-14410

PISTON

19

707-44-14180

RING,PISTON (KIT)

20

707-39-14820

RING,WEAR (KIT)

21

707-44-14910

RING

22

707-81-10150

COLLAR

23

07000-15100

O-RING

24

07000-15090

O-RING (KIT)

25

07001-05090

RING,BACK-UP (KIT)

26

01310-01216

SCREW

27

07020-00000

FITTING

28

22U-63-92170

TUBE,L.H.

|28

22U-63-92270

TUBE,R.H.

29

22U-63-92180

TUBE,L.H.

|29

22U-63-92280

TUBE,R.H.

30

01435-01055

BOLT

31

01435-01040

BOLT

32

07000-13030

O-RING (KIT)

33

707-88-31520

PLATE,L.H.

34

07283-32738

CLIP

35

01599-01011

NUT

36

01643-31032

WASHER

|37

707-99-58390

SERVICE KIT
