Запчасти Komatsu PC228US-3-YB ЦИЛИНДР СТРЕЛЫ(ДЛЯ США И СПЕЦИФ-Я С ОТВАЛОМ) (YELНИЗ.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

22U-63-X9340

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

22U-63-X9350

CYLINDER GROUP,R.H. (FINAL COATING)

|1

22U-63-02651

CYLINDER ASS'Y

1

22U-63-52740

CYLINDER

2

20Y-70-21670

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

22U-63-52720

ROD,PISTON

5

20Y-70-21360

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-13921

HEAD,CYLINDER

8

07179-13104

RING,SNAP

9

195-63-94170

SEAL,DUST (KIT)

10

707-52-90680

BUSHING

11

707-51-90030

PACKING,ROD (KIT)

12

07000-15120

O-RING (KIT)

13

707-35-91320

RING,BACK-UP (KIT)

14

707-51-90640

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-13471

PISTON

18

707-44-13180

RING,PISTON (KIT)

19

707-39-13110

RING,WEAR (KIT)

20

707-44-13911

RING

21

07000-15080

O-RING (KIT)

22

707-35-90940

RING,BACK-UP (KIT)

23

01310-01216

SCREW

24

22U-63-52770

TUBE,L.H.

|24

22U-63-52870

TUBE,R.H.

25

206-62-64270

TUBE,L.H.

|25

206-62-64290

TUBE,R.H.

26

01435-01055

BOLT

27

01435-01040

BOLT

28

07000-13030

O-RING (KIT)

29

206-63-51190

BRACKET,L.H.

|29

206-63-51290

BRACKET,R.H.

30

707-88-21310

BAND

31

01010-81035

BOLT

32

01643-51032

WASHER

33

07283-22738

CLIP

34

01599-01011

NUT

35

01643-31032

WASHER

|36

707-99-47780

SERVICE KIT
