Запчасти Komatsu PC228US-3-YB ПРАВ. КРЫШКА(YELНИЗ.)(№-) ЧАСТИ КОРПУСА

|1

22U-54-22341

COVER

|1

22U-54-22340

COVER,R.H.

1

COVER

|1

COVER,R.H.

2

22U-54-24480

LOCK (WELDED)

|2

198-54-41982

LOCK ASS'Y (WELDED)

3

22U-54-22291

SHEET

4

22U-54-22231NK

HINGE

5

01010-81230

BOLT

6

01643-31232

WASHER

7

22B-54-12340

BAR

8

22B-54-12330

CUSHION

9

20R-54-11460

SPRING

10

01023-10512

SCREW

11

205-54-53550

DOVE TAIL

12

01010-80616

BOLT

13

01643-30623

WASHER

14

01010-81225

BOLT

15

01643-31232

WASHER

|16

22U-54-22141

FRAME

|16

22U-54-22140

FRAME

16

FRAME

17

22U-54-22162

BRACKET

|17

22U-54-22161

BRACKET

18

01010-81225

BOLT

19

01643-31232

WASHER

20

20Y-54-11611

STOPPER

21

01580-11008

NUT

22

20Y-54-28170

BRACKET

23

01010-81225

BOLT

24

175-54-34170

WASHER

25

205-54-51970

DOVE TAIL

26

01010-80616

BOLT

27

01643-30623

WASHER

28

01010-81225

BOLT

29

175-54-34170

WASHER
