Запчасти Komatsu PC228US-3-YA ЦИЛИНДР 2-Й СТРЕЛЫ (ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ) (С LOTATION РУКОЯТЬ) (YELНИЗ.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XY120

BOOM CYLINDER GROUP

|1

707-01-0A580

BOOM CYLINDER ASS'Y

1

707-13-16820

CYLINDER

2

707-76-10270

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

707-58-11380

ROD

5

707-76-10270

BUSHING

6

07145-00100

SEAL,DUST (KIT)

7

707-27-16920

HEAD

8

198-63-94170

SEAL,DUST (KIT)

9

07179-13126

RING,SNAP

10

707-52-90850

BUSHING

11

707-51-11030

PACKING,ROD (KIT)

12

707-51-11640

RING,BUFFER (KIT)

13

707-35-91640

RING,BACK-UP (KIT)

14

07000-15150

O-RING (KIT)

15

01010-82085

BOLT

16

707-88-75310

WASHER

17

707-36-16380

PISTON

18

707-44-16180

RING,PISTON (KIT)

19

707-39-16820

RING,WEAR (KIT)

20

707-44-16910

RING

21

07000-15100

O-RING (KIT)

22

07001-05100

RING,BACK-UP (KIT)

23

01310-01216

SCREW

24

707-86-11700

TUBE

25

707-86-11710

TUBE

26

01435-01055

BOLT

27

07000-13035

O-RING (KIT)

28

707-88-22720

BRACKET

29

707-88-21480

BAND

30

01010-81240

BOLT

31

01643-51232

WASHER

32

07283-23442

CLIP

33

01599-01011

NUT

34

01643-31232

WASHER

|K

707-99-67050

SERVICE KIT
