Запчасти Komatsu PC228US-3-YA 1-Я СТРЕЛА ЦИЛИНДР (ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ) (YELНИЗ.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XY100

BOOM CYLINDER GROUP,L.H.

G-2

707-01-XY110

BOOM CYLINDER GROUP,R.H.

|1

707-01-0A560

CYLINDER ASS'Y

1

707-13-12270

CYLINDER

2

20Y-70-21230

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-58-85230

ROD,PISTON

5

20Y-70-21360

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-12921

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90610

BUSHING

11

707-51-85030

PACKING,ROD (KIT)

12

07000-15110

O-RING (KIT)

13

707-35-91220

RING,BACK-UP (KIT)

14

707-51-85640

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-12071

PISTON

18

707-44-12180

RING,PISTON (KIT)

19

707-39-12110

RING,WEAR (KIT)

20

707-44-12911

RING

21

01310-01216

SCREW

22

707-35-90930

RING,BACK-UP (KIT)

23

07000-15075

O-RING (KIT)

24

707-86-66400

TUBE,L.H.

|24

707-86-66410

TUBE,R.H.

25

20Y-63-52382

TUBE,L.H.

|25

20Y-63-52482

TUBE,R.H.

26

01435-01055

BOLT

27

01435-01040

BOLT

28

07000-13030

O-RING (KIT)

29

707-88-22600

BRACKET

30

707-88-22700

BRACKET,L.H.

|30

707-88-22710

BRACKET,R.H.

31

707-88-21251

BAND

32

01010-51035

BOLT

33

01643-51032

WASHER

34

07283-22738

CLIP

35

01599-01011

NUT

36

01643-31032

WASHER

|K

707-99-46140

SERVICE KIT
