Запчасти Komatsu PC228US-3 ПЕРЕГОРОДКА. (COVER) (/) (YELНИЗ.) ЧАСТИ КОРПУСА

|$8

22U-54-22953

COVER

1

COVER

2

22U-54-23670

SHEET

3

22U-54-22811

SHEET

4

22U-54-23660

SHEET

5

22U-54-22850

SHEET

6

22U-54-23250

SHEET

7

22U-54-23680

SHEET

8

22U-54-23850

SHEET

|$18

22U-54-22723

COVER

|$19

22U-54-22722

COVER

9

COVER

9

COVER

10

22U-54-23710

SHEET

11

01010-81220

BOLT

12

01643-31232

WASHER

13

01010-81230

BOLT

14

01643-31232

WASHER

|$31

22U-54-23330

COVER

15

PLATE

16

22U-54-22691

SHEET

17

01010-81230

BOLT

18

01643-31232

WASHER

19

205-54-76411

COLLAR

20

22U-54-22680NK

PLATE

21

01010-81230

BOLT

22

01643-31232

WASHER

23

205-54-76411

COLLAR

24

22U-54-23190NK

COVER

25

22U-54-11960

SEAL

26

01010-81230

BOLT

27

01643-31232

WASHER
